95932 - RDC54W
(Woods RDC54 54" Rear Discharge Mower)

Price: 2024
Brochure/Equipment photo

*Unique tapered deck design allows closer mowing around obstacles *Spring loaded idler provides correct belt tension without adjustment, significantly increasing belt life *Heat-treated, high lift blades ensure a finish quality cut *Baffling and rear discharge design ensure exceptional cut, discharge, and distribution of material *Deep deck design allows greater cutting volume with a better cut quality *3-year limited gearbox warranty - residential users *1-year limited gearbox warranty - commercial users *ASAE Quick Hitch Compatible Specifications *Model RDC54 *Cutting width 54" *Cutting height range 1" to 4-1/2" *Overall width 55.16" *Overall length 51.65" *Weight* 401 lbs *Tractor horsepower 15 - 25 *Tractor PTO speed 540 RPM *Hitch limited cat. 1 *Driveline cat. 3 *Gearbox horsepower 25 *Belt "B" size Kevlar *Blades (3) 1/4" x 2-1/2" *Number of blade spindles 3 *Blade tip speed 16,200 fpm *Blade overlap 1" *Deck thickness 10 gauge *Discharge rear *Rear chain shielding optional *Front anti-scalp roller optional *Caster Wheels Pneumatic (standard) 3.5 x 4 x 10 Solid Rubber (optional) 3.25 x 10


Available Optional Extras/Parts:
The above machine comes with solid tyres and chain shielding included.

We supply a full range of parts for this machine. For further information please contact our parts department on 08703 210256
